Continuous Glycerolysis

This is based on Sumwin's Continuous Glycerolysis technology.

It is Sumwin's proprietary technology to convert waste oils like

• POME (Palm Oil Mill Effluent),
• UCO (Used Cooking Oils),
• PAO (Palm Acid Oil),
• FAD (Fatty Acid Distillates) etc

into feedstock for Biodiesel or Animal feed.

           Our system consists of continuous Glycerolysis reactors which can convert high FFA (as high as 60%) to a low FFA product (max 0.2%) with an oil yield of around 99% in a very cost effective configuration. The main equipment consists of our proprietary design of pre-treatment to take care of the sludge and other impurities followed by series of reactors, vacuum system, feed oil pumps, chemical feed pumps, product transfer pumps, intermediate tanks, heat exchangers, flow meters, temperature transmitters, pressure transmitters, level transmitters and MCC/PLC panel. The processes in this plant are completely automated using PLC controls and SCADA monitoring system to guarantee process reliability.

Key Advantage of this Glycerolysis system as compared to alternate technologies are:

• This is continuous system as against batch system provided by others.
• No need to use any hazardous acid like HCL, H2SO4 etc.
• Low CAPEX because no need to use exotic material of construction.
• Optimized OPEX.
• Low Maintenance Cost with least down time.
• Oil yield of around 99%
• This system will provide a value addition to the extra waste oils that will be generated at palm oil mills due to segregation of waste oils for mitigating 3MCPDE/GE.

Please contact us so that we can review the kind of waste oils you have and how you can effectively convert it into more valuable feedstock for other products.  We can provide a complete turnkey proposal with ROI analysis based on value addition to the final product.
